DESCRIPTION

Basic Info

Model NO.	WHRB
Drum Placement	Horizontal Boiler
Pressure	High Pressure
Manufacturing Level	A
Burning Style	Cyclone Furnace
Usage	Industrial
Used for	Hrsg Used for Industry
Warranty	1year
Name	Waste Heat Recovery Boiler
Weight	Dependent
Transport Package	(20-Feet or 40-Feet
Specification	dependent
Trademark	xingfu boiler
Origin	Qingdao, China
Production Capacity	1000piece/Year

Product Description

Specification of HRSG waste heat steam boiler

1. The steam shall be produced by waste heat of production process, resulting in energy saving andincreasing benefit.2. The waste heat boiler shall feature the following advantages: compact structure, no pollution, smallsystem resistance, simple operation, safty and reliability, and full waste heat recovery.3. The design of waste heat boilers shall be in accordance with users' process parameter.

Boiler type Item	Q16-480 -2-1.0	Q33-490 -4-1.0	Q48-490 -6-1.0	Q50-500 -6-2.5/350	Q85-500- 10-2.5/350
Rated output (t/h)	2	4	6	6	10
Rated working pressure (Mpa)	1	1	1	2.5	2.5
Flue gas flow(peak) Nm3/h	16000	33000	48000	50000	85000
Inlet flue gas temperature°C	480	490	490	500	500
Heated surface of boiler proper (m²)	188	345	572	332	532
Heated surface of Superheater (m²)	--	--	--	18	26
Heated surface of Economizer (m²)	--	--	--	45	75
Maximum weight of transportation cargo (t)	8.9	15.2	23.5	Assembly	Assembly
System resistance (Pa)	< 1500	< 1500	< 1500	< 1000	< 1000
Scope of application	Power industry	Power industry	Power industry	Chemical industry	Chemical industry

FAQ

1. What is our Qualification?We are a Class A Boiler Manufacturer, with more than 30 years' experience in the field of boilers and pressure vessels.2. What is our product range?We specialized in manufacturing boilers,pressure vessels and boiler auxiliaries3. How many countries we have exported?We have exported to Bangladesh, South Africa, Malaysia, Philippines, Indonesia, Packistan, etc. Our product have been successfully exported to Europe,Africa,Latin America,South East Asia and Middle East countries and areas.4. What is our Warranty Period?The Warranty Period is ONE YEAR with lifelong service.
