DESCRIPTION

Basic Info

Model NO.	DL serials
Capacity	10-30L
Gas Type	Natural Gas
Type	Forced Exhaust
Energy Efficiency Grade	Two
Interior Material	Copper
Installation	Indoor Standard Installation
Housing Material	Stainless Steel
Control Mode	PC Edition
Usage	Bathroom, Kitchen
Certification	ISO9001
Transport Package	Carton
Specification	850*500*420
Trademark	Arcio
Origin	China
Production Capacity	800000

Product Description

* Big touch display with new design
*Fashionable appearance with nobleness and elegance
*Including 5 models and timing with 1 key
*Remote control system & wifi optional
* Classical double knobs control with easy operation
*Low noise, low carbon and energy-saving
* 24 safety protections
* Bithermic type(One heat exchanger)& Plate heat exchanger type (Two heat exchangers) available
* OEM & ODM solutions available

Model	L1PB18-B	L1PB20-B	L1PB24-B	L1PB26-B	L1PB28-B	L1PB32-B	L1PB36-B	L1PB40-B	L1PB50-B	L1PB55-B	L1PB60-B
Input power	18KW	20KW	24KW	26KW	28KW	32KW	36KW	40KW	50KW	55KW	60KW
Gas type	NG (G20)
Output power	16.2KW	18KW	21.6KW	23.4KW	25.2KW	28.8KW	32.4KW	36KW	45KW	49.5KW	54KW
Efficiency-CH	90%
Max Heating temp.	85ºC
Heating temp. range	30ºC~80ºC (Ground heating:30ºC~60ºC)
Efficiency-DHW	90%
Δt=25K rated water Capacity	9	10	12	13	14	16	18	20	25	27.5	30
Net weight (KG)	36	36	37	37	38	38	48	48	55	55	55
Gross weight (KG)	39	39	40	40	41	41	51	41	60	60	60
Product size(mm)	750*410*315						780*560*350		800*650*360
Packing size(mm)	825*465*390						895*615*415		920*750*460
Loading qty(20GP)	200	200	200	200	200	200	125	125	90	90	90
Loading qty (40HQ)	390	390	390	390	390	390	310	310	220	220	220
